Oil-Free Piston Pump

Home > Product > Vacuum Pump / Pressure Pump > Oil-Free Piston Pump >

Oil-Free Piston Pump

Max. vacuum: 100mbar, Max. Flow rate:34 L min

Model: V400

Order NO.: 167400-22

4736

Specific parameters will be adjusted according to product upgrades, without notice.

Quotation Request

PRODUCT OVERVIEW

Description

Chemvak V series vacuum pump is a piston-powered, oil-free pump. With innovative electronic, mechanical technology and human design concept make, compact and light weight, clean and maintenance free, safe and comfortable.

Features
No air pollution, maintenance free
Chemvak V series pumps are driven by Piston, without the need of lubricant, regular oil changes and maintenance; with no oil pollution.

Moisture trap with filter cartridge
Chemvak V series pumps are equipped with filter cartridge in air inlet to filter particle and moisture to prolong the life of pump.
 Oil-free

The oil-free piston vacuum pump provides continuous, reliable, high flow vacuum for your container
Vacuum regulator
Chemvak V series pumps are equipped with vacuum regulator to adjust vacuum.

Thermal protection device
Every motor of Chemvak V series pumps has a built-in thermal protection device to shut off the pump automatically when overheated and then resume working when the temperature cools down.

Application Areas
* Biology laboratories
* Food industry
* Microbiological detection
* Vacuum extraction
* Liquid filtration
* Vacuum drying
* Suspended solids measurement

Specifications

Model / Specifications

V400

Order No.

167400

Flow rate [m3/h] at atm. pressure

2.04

Flow rate [l/min] at atm. pressure

34

Ultimate vacuum [mbar abs.]

100

Max. Power P [W]

80

Max. current [A]

0.4

Motor speed [rpm]

1450

Hose connections [mm]

9

Noise [dB]

60

Dimensions W x H x D [mm]

310x152x165

Weight [kg]

5.4

Power supply

220V/50Hz
