Ultra High Torque Overhead Stirrer

Speed Range:20-800RPM,Maximum Viscosity:150000cps

Model: WB1800-C

Order NO.: 100601

1094

Specific parameters will be adjusted according to product upgrades, without notice.

Quotation Request

PRODUCT OVERVIEW

Description

Remotely Controllable High Torque / High Speed Stirrers C & EC Series

* Suitable for reaction systems and other high torque / high speed applications
* Set speed can be maintained when viscosity of liquid changes
* Brushless DC motor made in Germany, for high performance stirring processes
* Maintenance-free
* Quiet and reliable
* Digitally adjustable rotation speed and direction
* Remote controller can display actual speed and actual torque as well as the set speed
* Digital (RS-232/485) and analog communication available for remote PC or PLC control

Performance
* Years of vibration-free and silent operation.
* Powerful torque capable of handling high viscosity tasks.
* Maintenance of constant motor speed by control system even under conditions of changing viscosity.
* Best effort function intelligently manages its stirring speed to keep stirring even workload is out of its capacity.
* Prevention of accidental spills or splashes thanks to microprocessor controlled smooth start and stop functions.

Practical external controller.
* Intuitive and easy control with touch TFT.
* It enables convenient and safe external control without opening the sash of the fume hood or safety cabinet.



Compact and slim head design for diverse flexibility in configuring other test equipment and accessories. (optional)

Safety
* Sturdy aluminum main body efficiently absorbing and emitting the heat generated by the motor.
* Separated adapter from the main body minimizes the risks of electrical hazards to the users.


Specifications

Model

WB1800-C

Control Type

TFT Display for Speed and Torque and On-Touch Control

Torque Display Stirrer converts output current to torque, reflecting the changing load of motor

Speed Range (rpm)

20-800

Speed Accuracy(rpm)

±1

Maximum Viscosity (cps)

150000

Maximum Torque (N-cm)

1320

Rated Torque (N-cm)

188

Maximum Capacity (L) H2O

50

Power (W)

150

Dimensions (W × L × H in mm)

216×65×65

Motor Weight (Kg)

2.3

Order No.

100601
