Shaker Incubator

Home > Product > Shaker Incubator > Shaker Incubator >

Shaker Incubator

Volume:53L,Temperature Range:15~60℃

Model: WS-300R

Order NO.: W6095050

3883

Specific parameters will be adjusted according to product upgrades, without notice.

Quotation Request

PRODUCT OVERVIEW

Description

Combining a benchtop incubator/refrigerator with a dual-action (orbital and reciprocal) shaker, WS series shaking incubators offer versatility for a variety of biological and biotech applications.

Shaking Features
> Dual shaking modes: orbital or reciprocal.
> Speed range: 30 to 300 rpm.
> Programmable shaking motion.
- Timer range: 10 sec to 999 hr 59 min 59 sec.
- Forward & Backward, Pause: 10 sec to 59 min 59 sec.
> Selectable stroke length: 20, 30, 40mm.

Operating Features
> Temperature control:
+5℃ above ambient to 60℃ . (for WS-300 and WS-600)
+15℃ to 60℃ . (for WS-300R and WS-600R)
> Microprocessor PID control.
> Simple calibration and auto-tuning functions.
> Digital timer with delayed ON/OFF function: 1 min to 99 hr 59 min.
> High temperature limit setting and open door alarm.
> Convenient preset function for 3 most commonly used temperature settings.
> Up to 9 temperature steps and maximum 200 cycles of repetition and programmable for each profile.
> Adjustable 3-step fan speed with defrosting time and period control.
> Intuitive control panel with bright LED display (0.1℃ resolution) and push button keypad.
> RS-232 interface.

Optional Accessories
> Universal / Dedicated Platforms, Rubber Mats, Universal Attachments
> Flask Clamps, Funnel Clamps
> Test Tube Racks, Spring Wire Racks
> Microplate Holders (three styles)
> Lab Sticker

Constructional Features
> Maintenance-free and durable BLDC motor.
> High-velocity fan ensuring uniform temperature distribution and rapid thermal recovery.
> Convenient sample monitoring thanks to the transparent acryl lid and the fluorescent lamp.
> Gas spring lid supports providing soft closing, smooth motion, and stopping.
> Environment-friendly CFC-free refrigerant.

Specifications

Product Name WS-300R
Volume [L] 53
Temperature Range [℃ ] 15~60
Accuracy [℃ ] ±0.1 (38)
Stability [℃ ] ±1.0 (38)
Controller Push button keypad.; Digital Display with PID automatic regulation
Heater Heating Plate, 600W
Timer Start / Stop / Duration setting; 10sec ~999hr 59min 59sec
Shaker Controller PID automatic regulation
Power Unit Brushless motor
Methods Clockwise, Counter-clockwise, forth-back, interrupted,
Shaking Throw [mm] 20, 30 (standard), 40
Speed [rpm] 30 ~ 300
Stability [rpm] ± 1 (at 150rpm)
Dimensions Platform [W × D in mm] 350 × 350
Inside [W × D × H in mm] 410 × 410 × 320
Outside [W × D × H in mm] 440 × 740 × 625
Net Weight [kg] 85
Max. Load [kg] 10
Order No. W6095050

Accessories
