Viscometer

Home > Product > Auto Titrator/Viscometer/Density meter/Electrochemistry Analyzer/Refractometer > Viscometer >

Viscometer

Measuring range:10 to 320,000,000 cP;Speed:0.01 to 250rpm

Model: PREMIUM

Order NO.: VL1001647

264

Specific parameters will be adjusted according to product upgrades, without notice.

Quotation Request

PRODUCT OVERVIEW

Description

Innovative equipments with an advanced design and multifunctional viscosity measurements.

> Colour TFT screen for easy readings and fast data recognition.
> Intuitive full-touch keypad: data at your fingertips.
> New USB connection: Type A 2.0 generation for downloading data to the PC.

Screen Data:
Selected speed...........................................................................................r.p.m.
Selected spindle.............................................................................................SP
Viscosity reading.......................................................................cP (mPa·s) or cSt
Percentage of full scale....................................................................................%
Sample temperature.............................................................................. ºC or ºF
Shear Rate (with coaxial spindles) ............................................................SR (s-1)
Shear Stress (with coaxial spindles) .....................................................SS (N/m2 )
Density (introduced by the user) ................................................................g/cm3

Viscosity reading:
> Dynamic viscosity (cP or mPa·s)
> Kinematic viscosity (cSt).
> Units Converter from SI to CGS.

Program Features:
> Time to torque: Ending of the test upon reaching a programmed torque.
> Time to stop: Ending of the test upon reaching a programmed time.
> Multistep: posibility to programme several essays in a successive way
> Ramps: essay programation with an initial and final speed in an specific time
> 10 working memories.

Other main features:
> AUTO-TEST with visual and resonant alarm
> AUTO-RANGE function
> Temperature Reading through PT100 probe
> User-enabled viscosity and temperature calibration
> 6 language options
> Port: USB
> Datalogger: Posibility to tranfer data to a pendrive into Excel format
> Statistics: Posibility to see data in graphics

Standard delivery:
• The equipement is supplied complete with standard spindles (4 spindles for L model / 6 spindles for R and H models)
• Viscometer stand
• Spindle protector
• Temperature probe PT100
• Carrying case
• USB cable
• External power supply

Technical File
> Precision: +/- 1% full scale of range
> Resolution:
   For a minus viscosity of 100 cP : 0.01 cP
   For a major viscosity of 1000 cP : 0.1 cP
   For a major viscosity of 5000 cP : 1.0 cP
   For a major viscosity of 10.000 cP : 5.0 cP
   For a major viscosity of 25.000 cP : 10.0 cP
   For a major viscosity of 50.000 cP : 25.0 cP
   For a major viscosity of 100.000 cP : 100.0 cP
   For a major viscosity of 1.000.000 cP : 1.000.0 cP
> Repeatability: 0.2%
> Temperature probe features: Temperature limits: -40ºC to 300ºC -40ºF to 572ºF Resolution: 0.1ºC / -17.722 ºF
> Precision: +/- 0.2ºC / +/- 17.666 ºF
> Type of probe: PT100
> Supplied at 110-240VAC, 50/60 Hz.
> Software: FGB Data Boss The FGB Data Boss software complies the FDA 21CFR PART 11 regulation

Accessories
> APM Small Sample Adapter with circulation jacket (without TL or TR spindles) Sample volume (6.7 - 13 ml.) Compatible with Brookfield viscometers
> APM/B Small Sample Adapter without circulation jacket (without TL or TR spindles). Sample volume (6.7 - 13 ml.) Compatible with Brookfield viscometers
> LCP Low Viscosity Adapter with circulation jacket (with spindle) Sample volume (16 ml.) Compatible with Brookfield viscometers
> LCP/B Low Viscosity Adapter without circulation jacket (with spindle) Sample volume (16 ml.) Compatible with Brookfield viscometers
> HELDAL Helix Drive Unit. Accessory for measuring non-flowing substances viscosity (with spindles)
> THERMOSPHERE Temperature control unit up to 300 ºC

Spindles:
AISI 316 Stainless steel spindle, easily to identify according to its letter and number, in terms of the range of viscosity.

Standards:
These are the standards our units follow:
• BS: 6075, 5350
• ISO:2555,1652
• ASTM: 115, 789, 1076, 1084, 1286, 1417, 1439, 1638, 1824, 2196, 2336, 2364, 2393, 2556, 2669, 2849, 2983, 2994, 3232, 3236, 3716

Order Information

Model PREMIUM L PREMIUM R PREMIUM H
Order No. VL1001647 VL1001648 VL1001649
Measuring range 10 to 6,000,000 cP 25 to 40,000,000 cP 200 to 320,000,000 cP
Standard spindles L1,L2,L3,L4 R2,R3,R4,R5,R6,R7 R2,R3,R4,R5,R6,R7
Speed (r.p.m) 0.01 to 250 0.01 to 250 0.01 to 250
Number of speeds 2600 2600 2600
Power supply 100~240V 50/60Hz, 25W 100~240V 50/60Hz, 25W 100~240V 50/60Hz, 25W
Weight 5kg 5kg 5kg
