Mode: SK172.1F-(80S/4 80LH/4 71L/4 80S/4/2G 80LH/4/2G), Power 0.37-0.75kW
Model:
Order NO.:
331
Specific parameters will be adjusted according to product upgrades, without notice.
|
Order No. |
2021-001-06 |
2021-001-07 |
2021-003-05 |
2022-001-06 |
2022-001-07 |
|
Description |
Motor |
Motor |
Motor |
Motor (ATEX) |
Motor (ATEX) |
|
Mode |
SK172.1F-80S/4 |
SK172.1F-80LH/4 |
SK172.1F-71L/4 |
SK172.1F-80S/4/2G |
SK172.1F-80LH/4/2G |
|
Power |
0.55kW |
0.75kW |
0.37kW |
0.55kW |
0.75kW |
Mounting Flange
|
BD (mm) |
AJ |
AK |
BB |
BF |
GA |
|
|
4.72 (120) |
3,937 |
3,150 |
+0.0005 -0.0003 |
0,12 |
0,26 |
0,31 |
|
5.51 (140) |
4,528 |
3,740 |
+0.0005 -0,0004 |
0,12 |
0,35 |
0,31 |
|
6.30 (160) |
5,118 |
4,331 |
+0.0005 -0,0004 |
0,14 |
0,35 |
0,39 |
|
7.87 (200) |
6,496 |
5,118 |
+0.0006 -0,0004 |
0,14 |
0,43 |
0,47 |
Motor Dimensions
|
Standard efficiency |
63S/L |
71S/L |
80S/L |
90S/L |
|
Premium efficiency |
|
|
80LP |
90SP/LP |
|
AB |
4,51 |
4,86 |
5,59 |
5,79 |
|
AB (BR) |
4,84 |
5,24 |
5,59 |
5,79 |
|
C |
14,07 |
14,93 |
15,80 |
17,33 |
|
C (BR) |
16,27 |
17,22 |
18,32 |
20,29 |
|
FP |
5,08 |
5,72 |
6,43 |
7,19 |
|
DB2 |
- |
- |
0,30 |
0,65 |
