Bottom screw thread #:#50/#80
Model: 6386-60
Order NO.: 6386-60
1186
Specific parameters will be adjusted according to product upgrades, without notice.
Rugged, heavy wall reactor, jacketed for cooling and/or heating of reaction material. With 60mm, 100mm, or 150mm Schott® style flange with o-ring groove at top, for connection to 6527, 6528 or 6529 heads, with 6517 quickrelease clamp.
Bottom has an Screw thread (internal glass thread) for installing 5838-83 (size 50) or 5857-86 (size 80) bottom adapter with filter support and drain valve. Body is jacketed with size 28/15 o-ring ball joints on inlet/outlet, sealed tangentially for more efficient circulation. Head has three 24/40 joints on 60mm size; four 24/40 joints on 100mm and 150mm sizes. Complete item consists of: reactor body with 60mm CAPFE o-ring, head with joints, 6517 clamp, PTFE bottom adapter with CAPFE o-ring (with perforated plate — #80 thread only), retainer ring, 350 micron polypropylene screen support, and 100 micron polyethylene support, 5844 adapter, 5839 shutoff valve (optional larger valve is available), non-flaking 8066 bearing, 8075 stirring rod, 8089 multi-paddle agitator.
For replacement glass fritted support, polyethylene support, or polypropylene screen, see 5848 or 5814. For condenser and funnel, see 6029 and 7298; stoppers with 24/40 joints, see 8250. For stirring motor, see 13511 or 13566 motor; for chuck, see 8124 or 8126. Use 7855-829 CAPFE O-ring for #50 adapter, 7855-864 for #80 bottom adapter.
> Stand and Support Shelf not included.
> 150mL size requires chain clamp rather than a shelf.
> For #80, bottom also available with 1/2" MNPT.
Ball Joint Inlet/Outlet (28/15) | ||||||
Capacity, mL | Flange I.D., mm (in.) | Bottom screw thread | Body I.D., mm | Approx. Height*, mm | Top CAPFE O-Ring | Order No. |
150** | 60 (2.4) | #50 | 60 | 100 | 7855-878 | 6386-40 |
600** | 60 (2.4) | #50 | 83 | 205 | 7855-878 | 6386-45 |
1000 | 100 (4) | #80 | 100 | 180 | 7855-880 | 6386-50 |
2000 | 100 (4) | #80 | 130 | 210 | 7855-880 | 6386-55 |
3000 | 150 (6) | #80 | 150 | 205 | 7855-881 | 6386-60 |
6000 | 150 (6) | #80 | 150 | 395 | 7855-881 | 6386-65 |
Screw thread Inlet/Outlet (#11, 3000 & 6000mL are #15) | ||||||
150** | 60 (2.4) | #50 | 60 | 100 | 7855-878 | 6386-440 |
600** | 60 (2.4) | #50 | 83 | 205 | 7855-878 | 6386-445 |
1000 | 100 (4) | #80 | 100 | 180 | 7855-880 | 6386-450 |
2000 | 100 (4) | #80 | 130 | 210 | 7855-880 | 6386-455 |
3000 | 150 (6) | #80 | 150 | 205 | 7855-881 | 6386-460 |
6000 | 150 (6) | #80 | 150 | 395 | 7855-881 | 6386-465 |
* Height measurements are measured from top of flask flange to seal on top thread.
** 150mL and 600mL heads have angled side necks.
